When you're navigating in the wilderness, understanding terrain features is a critical skill. Maps are powerful tools, but knowing how to interpret contour lines, elevation changes, and key terrain landmarks in relation to your surroundings can make the difference between staying on course or getting lost. In this post, we’ll cover how to apply magnetic north, true north, and declination to your navigation and how to use a map protractor efficiently.
Magnetic North vs. True North
One of the most important concepts in land navigation is the difference between magnetic north and true north.
-
True North: This points directly to the geographic North Pole.
-
Magnetic North: This is where your compass needle points, which shifts slightly over time due to changes in Earth’s magnetic field.
The difference between these two is called declination, which varies by location and must be accounted for when using a compass with a map.
Understanding Declination
Declination is measured in degrees east or west, depending on whether magnetic north is to the right or left of true north in your region. A map’s declination value is typically found in the legend or margin.
Where to Find Declination on a Map
On topographic maps, the declination diagram is usually located in the lower margin, near the scale and contour interval information. It consists of a simple graphic showing the angle between True North (TN), Magnetic North (MN), and sometimes Grid North (GN). This information is essential for adjusting your compass readings to ensure accurate navigation.
Adjusting for Declination
-
If the declination is east, subtract the declination angle from your bearing.
-
If the declination is west, add the declination angle to your bearing.
Failing to adjust for declination can cause navigation errors—even a few degrees off over long distances can put you far from your intended location.
Using a Map Protractor
A map protractor is an essential tool for accurately plotting bearings and distances on a topographic map. It helps you measure angles from grid north (which is often aligned with true north) and translate them to your compass.
Steps to Use a Map Protractor:
-
Align the Protractor: Place the center over your starting point on the map.
-
Rotate for Bearing: Rotate the protractor so that its north arrow matches the map’s north grid lines.
-
Read the Bearing: Find the degree reading where your destination line crosses the protractor’s scale.
-
Adjust for Declination: Apply the correct adjustment before setting your compass.
Practical Application in the Field
-
Identify Terrain Features: Compare contour lines with what you see in your environment.
-
Confirm Landmarks: Check ridges, valleys, and other key features against your map.
-
Use Handrails: Follow natural features like rivers or ridgelines to guide your movement.
-
Check Your Bearing Regularly: Adjust as needed to stay on course.
Keeping Your Navigation Gear Secure
When navigating off-grid, keeping your map, compass, and protractor accessible and protected is essential. The Gnome Chest Pack from Squatch Survival Gear is an ideal solution. Designed for EDC and field use, it allows you to store your essential navigation tools within easy reach while ensuring they stay secure and weather-resistant. With its ergonomic X-harness or single-strap configuration, the Gnome keeps everything close to the chest—literally. Whether you’re moving through dense terrain or open landscapes, having your navigation tools in a dedicated, American-made tactical survival backpack keeps you ready for any challenge.
By mastering these navigation techniques, you can confidently move through the wilderness without relying solely on GPS. Up next in our land navigation series, we’ll dive deeper into advanced navigation tools and how they integrate with traditional map and compass skills.
